Features
- Real-Time, Uncompressed Video Transmission
- Supports Both Singlemode And Multimode Fiber
- Supports The Following Formats :
- Error Free Pathological Pattern Performance
- Small Tx Easily Mounts on Back of Cameras
- Supports Embedded Audio and Metadata
- Distances in Excess of 30 km
- 5 VDC Power Pack or USB Hub
- Led Indicators for :
- Power
- Rx Optical Power
- Tx Video Signal Present
- Laser Over Current
- 10Hz to 20KHz audio bandwidth
- Greater than 90dB SNR for superb audio quality
Signal Specifications
2 × 3G-SDI Video (HG)
| Formats | 19.4 Mbps (SMPTE 310M) 143 To 540 Mbps SMPTE 259M/344M 1.485 Gbps SMPTE 292M HDTV DVB-ASI at 270 Mbps 2.97Gbps (3G) SMPTE 424M SMPTE 305M SDTI Rates Nominal Level 0.8 Vp-p, 1.0 Vp-p max. |
|---|
| Data Rate | 19Mb/s - 1.5Gb/s Impedance 75 Ohm GainUnity Input Coupling AC Return Loss >15 dB |
|---|
| Jitter | < 0.2 UI Cable Equal. 0-200m @ 1.5 Gb/s Bit-Error Rate (0 to -20dBm) 10-12 |
|---|
4 × Audio Unbalanced HIZ (AB)
| I/O Impedance | 600 Ohms (Bal./Un Bal.) |
|---|
| Frequency Responce | 10 Hz to 20 KHz |
|---|
| SNR | >90dB (Weighted)@ 1 KHz |
|---|
| In/Out Level | -8 to +8 dBm(4Vp-p max.) (+18 dBm optional) |
|---|
| THD | <0.01% @ 1KHz |
|---|
| Resolution | 24 Bit |
|---|
Indicators
3G-SDI Video
| Green | Signal Power Level ( RX ) |
|---|
| Green | Signal Present ( TX ) |
|---|
| Green | Signal Lock (TX) |
|---|
| Green | SDI Present (TX) |
|---|
| Green | HD-SDI Present (TX) |
|---|
Audio Unbalanced HIZ
| Red | Audio Overload |
|---|
| Green | Audio Present |
|---|
Physical
| Dimensions | 20 (W) x 127 (H) x 160 (D) mm (0.8 x 5.0 x 6.3 inch) |
|---|
| Weight | 450 gms (16 Oz) |
|---|
| No. of Slots | 2 |
|---|
Environmental
| Operating Temperature | -34°C to +70°C |
|---|
| Storage Temperature | -55°C to +80°C |
|---|
| Relative Humidity | 0 to 95% Non-condensing |
|---|
Quality
MTBF >170,000 hours @ Ground Fix 35 °C per MIL217F
Optical Specifications & Ordering
| Part number | Code | Fiber type | Wavelength |
Output (dBm) | Sensitivity (dBm) | Budget (dB) |
Dynamic range (dB) | Connector |
FXA/FXB-1HG2AB/1HG2AB-20 |
20 |
CWDM, Singlemode 9 / 125 |
1290, 1310, 1330, 1350 nm |
+1 (per channel) |
-20 |
21 |
20 |
ST, FC |
FXA/FXB-1HG2AB/1HG2AB-21 |
21 |
CWDM, Singlemode 9 / 125 |
1510, 1530, 1550, 1570 nm |
+1 (per channel) |
-20 |
21 |
20 |
ST, FC |
